BC-P Single point load cell, 150kgf - 500kgf

⊙FEATURES
NTEP III 5,000S approved(Handbook 44)
OIML C3 approved(OIML R60)
Off center compensated(OIML R76)
Protection class IP65

⊙OPTIONS
NTEP III 5,000S approved(A5)
OIML C3 approved(C3)
6-wires connection

⊙Material
Anodized Aluminum

⊙Mounting
Socket-head cap screw 5/16-18UNC(10.9)
Tightening torque: 29Nm

⊙Cable
Braided Shield 4-wire round cable
with PVC-Jacket

⊙Maximum Platform Size
600 x 600mm

⊙Ordering Information
BCM - XXXL - I
          ━┳
       Capacity in kg

Max. capacity	kgf	50, 75, 100, 150, 200, 300, 500
Rated output Zoro balance	mV/ V mV/ V	1.2 (Approx.) 0 ± 0.06
Accuracy class		D3	C3, A5
Combined error Repeatability Creep for 30min. Temperature effect on            Zero Value            Output value	% % % %/ 10℃ %/ 10℃	0.03 0.01 0.03 0.04 0.015	0.02 0.01 0.017 0.014 0.011
Excitation            Recommended            Maximum Resistance            Input            Output            Insulation	V V Ω Ω MΩ	10 15 400 ± 20 350 ± 3.5 ＞2,000
Compensated temperature range Operating temperature range	℃ ℃	-10 to +40 -20 to +70
